    Ral 9016 Painted Aluminum Sheet , Color Coated Aluminum Coil AA3003 H24

    Ask Lasest Price
    Brand Name : Dingang
    Model Number : Dingang - PPAL
    Certification : SGS,ITS,BV
    Price : Negotiable
    Supply Ability : 5000 Tons / Per Month
    Delivery Time : Within 35 Days After Order Confirmed And Down Paymetn Received
    Payment Terms : T/T,L/C
    • Product Details
    • Company Profile

    Ral 9016 Painted Aluminum Sheet , Color Coated Aluminum Coil AA3003 H24


    Ral 9016 Painted Aluminum Sheet AA3003 H24 Used For Roofing Material


    Color coated aluminum (prepainted aluminum),which is produced with aluminum sheet or coil and processed by coating with color or pattern.
    In common sense, here are two kinds of coating PVDF and PE.Compared with other section steel prepainted aluminum coil is the more popular material, because of its excellent property. Firstly the property is very stable so the surface is erosion resistant, warranty could up to 30 years long after special treatment. Then,the density is the lowest among metal material when volume is fixed.


    Specifications:


    Alloy:3003,3004,3105,
    Temper:H16/H18/H22/H24
    Standard: ASTM, ASME, AISI, JIS, DIN, EN, ISO, GB And Etc
    Thickness:0.35mm -2.00mm
    Width:30-2500mm
    Thickness Of Paint Layer:(PVDF) more than 25 micron; (PE) more than 18 micron
    Interior Diameter: 405mm, 505mm
    Color: Ral Color Code (Ral 9006,9017,9016 and any other color sample from customer)
    Coating Hardness: More Than 2H(pencil hardness)
    Impact Resistance: No Cracking And Peeling (50kg/cm,ASTMD-2794:1993)
    Flexibility (T-bend): No More Than 2T
    MEK Resistance: More Than 100




    Paint Performance:

    Test Item

    Paint

    PVDF

    PE And Others

    With Varnish

    Without Varnish

    Paint Film Thickness, μ

    ≥22

    ≥30

    ≥18

    Shine Tolerance

    Shine≥80 Unit, ±10 Unit Allowed

    Shine≥20-80 Unit, ±7 Unit Allowed

    Shine<20 Unit, ±5 Unit Allowed

    Pencil Hardness

    ≥1H

    Abrasion Resistance, L/μm

    ≥5

    --

    T-bend

    ≤2T

    ≤3T

    Impact Strength

    50KG.CM Without Depainting And Crack

    Adhesive Force (Class)

    ≥1

    Boiling Water Resistance

    Unvarying

    Chemical Resistance

    Acid Endurance

    Unvarying

    Alkali Stability

    Unvarying

    Oil Resistivity

    Unvarying

    Resistance To Solvent

    ≥70

    ≥50

    Scrub Resistance

    ≥10000 Times Unvarying

    Dirt Resistance

    ≤15%

    --

    Salt Spray Resistance(class)

    ≥ 2 class

    --


    Packing:


    Export Standard Seaworthy Packing With Wooden Pallets In Horizontal Or Vertical (As Per The Requirements Of Clients)



    Appliance:


    As per types of surface coating of paint, color coated aluminum coils can be divided into polyester (PE) coated aluminum coil, fluorocarbon (PVDF) coating aluminum coil and Epoxy coated aluminum coil.
    Color coated aluminum coil is widely used in the roofing and cladding system, ceiling system, curtain wall plate, shutter, gutter, composite panel, can, home appliances board and embossed aluminum coil.
