    Gauge 0.68mm thickness polyester color coated aluminum sheets for production Gutters

    Ask Lasest Price
    Brand Name : Dingang
    Model Number : PPAL
    Certification : SGS,ITS,BV
    Price : Negotiable
    Payment Terms : T/T,L/C
    Supply Ability : 5000 Tons / Per Month
    Delivery Time : Within 35 Days After Order Confirmed And Down Paymetn Received
    • Product Details
    • Company Profile

    Gauge 0.68mm thickness polyester color coated aluminum sheets for production Gutters

    Color Coated Aluminum Sheet (Pre-painted Aluminum)

    Color coated aluminum (prepainted aluminum), which is produced with aluminum sheet or coil and processed by coating with color or pattern.
    In common sense, here are two kinds of coating PVDF and PE.Compared with other section steel prepainted aluminum coil is the more popular material, because of its excellent property. Firstly the property is very stable so the surface is erosion resistant, warranty could up to 30 years long after special treatment. Then,the density is the lowest among metal material when volume is fixed.


    Specification:

    Alloy:1xxx/3xxx/5xxx And Etc
    Temper:O/H16/H18/H22/H24(All According Customers' Requirement)
    Standard: ASTM, ASME, AISI, JIS, DIN, EN, ISO, GB And Etc
    Thickness:0.2mm -2.5mm
    Width:30-1600mm
    Thickness Paint Layer:(PVDF) more than 25 micron; (PE) more than 18 micron
    Interior Diameter: 405mm, 505mm, 150mm etc.
    Color: RAL# Or As Per Customers' Samples
    Coating Hardness: More Than 2H(pencil hardness)
    Impact Resistance: No Cracking And Peeling (50kg/cm,ASTMD-2794:1993)
    Flexibility (T-bend): No More Than 2T
    MEK Resistance: More Than 100

    Types:

    Paint Performance
    Test Item
    Paint
    PVDF
    PE And Others
    With Varnish
    Without Varnish
    Paint Film Thickness, μ
    ≥22
    ≥30
    ≥18
    Shine Tolerance
    Shine≥80 Unit, ±10 Unit Allowed
    Shine≥20-80 Unit, ±7 Unit Allowed
    Shine<20 Unit, ±5 Unit Allowed
    Pencil Hardness
    ≥1H
    Abrasion Resistance, L/μm
    ≥5
    --
    T-bend
    ≤2T
    ≤3T
    Impact Strength
    50KG.CM Without Depainting And Crack
    Adhesive Force (Class)
    ≥1
    Boiling Water Resistance
    Unvarying
    Chemical Resistance
    Acid Endurance
    Unvarying
    Alkali Stability
    Unvarying
    Oil Resistivity
    Unvarying
    Resistance To Solvent
    ≥70
    ≥50
    Scrub Resistance
    ≥10000 Times Unvarying
    Dirt Resistance
    ≤15%
    --
    Salt Spray Resistance(class)
    ≥ 2 class
    --

    Appliance


    As per types of surface coating of paint, color coated aluminum coils can be divided into polyester (PE) coated aluminum coil, fluorocarbon (PVDF) coating aluminum coil and Epoxy coated aluminum coil.
    Color coated aluminum coil is widely used in the roofing and cladding system, ceiling system, curtain wall plate, shutter, gutter, composite panel, can, home appliances board and embossed aluminum coil.
