    3005 H18 Copper Color Coated Aluminum Coil For Forming Roofing Tiles

    Ask Lasest Price
    Brand Name : Dingang
    Model Number : Dingang - Color coated Aluminum
    Certification : SGS,ITS,BV
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 000 Metric Tons/Per Year
    Delivery Time : 15 - 35 Days
    • Product Details
    • Company Profile

    3005 H18 Copper Color Coated Aluminum Coil For Forming Roofing Tiles

    3005 H18 Copper Color Coated Aluminum Coil for forming Roofing Tiles

    Color Coated Aluminum (Pre-painted Aluminum --- PPAL)
    Color coated aluminum (prepainted aluminum),which is produced with aluminum sheet or coil and processed by coating with color or pattern.
    In common sense, here are two kinds of coating PVDF and PE.Compared with other section steel prepainted aluminum coil is the more popular material, because of its excellent property. Firstly the property is very stable so the surface is erosion resistant, warranty could up to 30 years long after special treatment. Then,the density is the lowest among metal material when volume is fixed.

    Product Details:


    Alloy:AA1050,1060,1100,3003,3004,3105,5052,5005,5754,5083,6061,6063,8011 EtcTemper:O,H12,H14,H16,H18,H24,H26, H32,H34,H111,H112,T3,T5,T6 Etc
    Coating Type:PE Or PVDFInterior Diameter:508mm
    Material Width:From 30 To 2500mmMaterial Thickness:0.1-2.5mm
    Color Option:Ral Color Code Or As Per Clients Requirements And Sample

    Specifications:


    Standard: ASTM, ASME, AISI, JIS, DIN, EN, ISO, GB Etc
    Thickness:0.1mm -2.5mm
    Width:30-2500mm
    Thickness Paint Layer:(PVDF) more than 25 micron; (PE) more than 18 micron
    Interior Diameter: 405mm, 505mm, 150mm etc.
    Color: Ral Color Code Or As Per Clients Requirements And Sample
    Coating Hardness: More Than 2H(pencil hardness)
    Impact Resistance: No Cracking And Peeling (50kg/cm,ASTMD-2794:1993)
    Flexibility (T-bend): No More Than 2T
    MEK Resistance: More Than 100

    Color Coated Aluminum Types:


    Paint Performance:


    Test ItemPaint
    PVDFPE And Others
    With VarnishWithout Varnish
    Paint Film Thickness, μ≥22≥30≥18
    Shine ToleranceShine≥80 Unit, ±10 Unit Allowed
    Shine≥20-80 Unit, ±7 Unit Allowed
    Shine<20 Unit, ±5 Unit Allowed
    Pencil Hardness≥1H
    Abrasion Resistance, L/μm≥5--
    T-bend≤2T≤3T
    Impact Strength50KG.CM Without Depainting And Crack
    Adhesive Force (Class)≥1
    Boiling Water ResistanceUnvarying
    Chemical ResistanceAcid EnduranceUnvarying
    Alkali StabilityUnvarying
    Oil ResistivityUnvarying
    Resistance To Solvent≥70≥50
    Scrub Resistance≥10000 Times Unvarying
    Dirt Resistance≤15%--
    Salt Spray Resistance(class)≥ 2 class--

    Appliance:


    As per types of surface coating of paint, color coated aluminum coils can be divided into polyester (PE) coated aluminum coil, fluorocarbon (PVDF) coating aluminum coil and Epoxy coated aluminum coil.


    Color coated aluminum coil is widely used in the roofing and cladding system, ceiling system, curtain wall plate, shutter, gutter, composite panel, can, home appliances board and embossed aluminum coil.
