    5052 H18 0.8MM Thickness Color Coated Aluminum Sheet For Roofing

    Ask Lasest Price
    Brand Name : Dingang
    Model Number : 5000 series
    Certification : SGS,ITS,BV
    Price : Negotiable
    Payment Terms : L/C,T/T
    Supply Ability : 100 000 Metric Tons/Per Year
    Delivery Time : 15 - 35 Days
    • Product Details
    • Company Profile

    5052 H18 0.8MM Thickness Color Coated Aluminum Sheet For Roofing


    Material Properties

    Alloy Composition: 5052 belongs to the Al-Mg alloy series (2.2-2.8% magnesium content) with trace elements like chromium and manganese, offering excellent corrosion resistance and weldability.


    Mechanical Properties:

    Tensile Strength: 170-305 MPa (annealed state). The H18 temper enhances strength through cold working, ideal for roofing structural requirements.

    Elongation: Approximately 12-20%, balancing plasticity and anti-deformation capabilities.

    Surface Treatment: Color coating (e.g., polyester or PVDF) improves weather resistance, corrosion resistance, and aesthetics, with common finishes including silver and custom colors.



    Product Parameters of Color Coated Aluminum Sheets


    Productcolor coated aluminum sheet
    Thickness0.2-1.6mm
    Width30-1600mm
    Material1050, 1060, 1100, 3003, 3004, 3105, 5052, 5005, 5754, 5083, 6061,8081 etc
    TemperO, H12, H14, H16, H18, H24, H26, H32, H34, etc
    LengthAs Alient's Demand
    ColorRAL, Pantone Color Or As Alient's Demand
    Coating thicknessPVDF Paint Coating: Not Less Than 25um

    PE Paint Coating : Not Less Than 18um
    PackingExport Standard Wooden Pallets (Eye To Wall,Eye To Sky)
    Payment TermsL/C at sight or 30% T/T in advance as deposit, and 70% balance against the B/L copy.
    MOQ3 Tons Per Specification
    Delivery TimeWithin 30-45 Days
    Loading PortShanghai,Ningbo,Qingdao,Tianjin Port and Etc
    ApplicationAluminum Roofing,ACP,Roller Shutter Window,Roller Shutter Door,Aluminum Ceiling,Aluminum Grilling,Aluminum Downspout System,Home Appliance's Plate, body tank of cold chain truck,high speed rail,aluminum pull ring,food packaging,outer packing case of capacitor,external contour of letter channel


    Application Scenarios

    • Roofing: Suitable for metal roofing, corrugated sheets, and roofing panels, especially in humid or corrosive environments (e.g., coastal areas).
    • Architectural Decoration: Can be used for façades, curtain walls, and sunshades, combining functionality and visual appeal.
    • Other Uses: Transportation vehicles, marine sheet metal parts, electrical enclosures, etc.



    Key Advantages

    • Corrosion Resistance: Al-Mg alloy inherently resists corrosion, further prolonged by color coating.
    • Formability: Excellent cold-working properties (e.g., stamping, bending) for easy roofing installation.
    • Lightweight: Density ~2.7g/cm³ reduces roof load and installation complexity.
    • Eco-Friendly: Recyclable, aligning with green building trends.
