    Regular Spangle Surface Aluzinc Coated Steel For Appliances

    Ask Lasest Price
    Brand Name : Dingang-GL
    Model Number : SPCC,SPCD,SPCE,DX51/52/53/54D+Z,Q195/215/235 And Etc
    Certification : ITS SGS BV
    Price : USD700 Per Metric Ton
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300000Metric Tons / Year
    Delivery Time : 15 - 35 Work Days
    • Product Details
    • Company Profile

    Regular Spangle Surface Aluzinc Coated Steel For Appliances


    0.18 - 2.5 mm Thickness Aluzinc Coated Steel , Hot - Dip GL Sheet For Appliances


    Profile :
    Galvalume Steel Is Tthe Plating Coat Of Aluminum-zinc Alloy Armor Plate,And Its Composition Is 55 % Al , 43.4 % Zn And 1.6 % Si . The Plate With Smooth Surface And Excellent Corrosion Resistance Of The Atmosphere , Which Is 2 To 6 Times Higher Than Hot-Dip Galvanized Sheet Of The Same Thickness Of Coating .


    Specifications of Aluzinc Coated Steel :

    ■Standard : ASTM A792 / JIS G3321 / GB / T14978 - 2008 / EN10326 - 2004
    ■Grade : SGLCC / SGLCD / SGLC400~570 / DC51D + AZ ~ DC54D + AZ
    ■Thickness : 0.15-2.5 mm
    ■Width : 600 - 1250 mm ( Usually 914 mm / 1219 mm / 1220 mm / 1250 mm)
    ■Base Metal : Cold - Rolled Steel
    ■Al-Zinc Coating : 50 - 150 g / sqm
    ■Coil Internal Diameter : 508 mm / 610 mm
    ■Surface Treatment : Chromate Passivated , Non - Chromate Passivated , Oiled , Anti - finger Print And Etc
    ■tolerance thickness : + / - 0.05 mm , tolerance width : + 5 / - 2 mm , total quantity : + / - 10 % , alu - zinc coating : + / - 10 %
    ■Packing Condition : Seaworthy

    Characteristics :
    GL are 3 ~ 6 times more corrosion - resistant compared to GI , but has a similar level of processability and weldability and can replace GI, and in particular is most suitable when replacing GI that require thick galvanized layers and high corrosion resistance .

    Only galvanized steel sheet that is used for roofing and walls without painting because of its unique silver spangles and beautiful appearance and high - corrosion resistance, and is used as a cool roofing material because of its excellent heat reflection qualities .

    Can replace aluminum gilded steel sheets because for certain purposes of its electrical conductivity and its heat-resistance qualities even at high temperatures that do not exceed 315 ℃ .

    Has greater surface hardness than GIs , and is much more wear - resistant .

    Corrosion resistance increased more with resin-coating treatment , which enables roll forming or press forming without the spraying of processed oils .

    Application of Aluzinc Coated Steel :
    Infrastructure : Roofing / External Siding / Garage / Shutter
    Household Appliances : Oven / Air - Conditioning Ventilation System / Solar Water Heater / Electronics
    Automobile : Mobile Muffler / Vent Pipe / Catalysis Converter Heater Shield / Bottom Accessories
    Industrial Instrument : Electric Control Cabinet / Industrial Freezer Chest

    Chemical Requirements :

    Chemical Requirements For Structure Steel

    Composition , % - Heat Analysis Element , Maximum , Unless Otherwise Shown
    DesignationCMnPSCuNiCrMoVCbTiaNb
    G2300.201.350.040.040.250.200.150.060.0080.0080.025*
    G2550.201.350.100.040.250.200.150.060.0080.0080.025*
    G2750.251.350.100.040.250.200.150.060.0080.0080.025*
    G3400.251.350.200.040.250.200.150.060.0080.0080.025*
    G5500.201.350.040.040.250.200.150.060.0080.0150.025*
