    Regular Spangle Aluzinc Coated Steel For Pipes And Verandas 0.16-3.0 mm Thickness


    Aluzinc Coated Steel Of 914 / 1000 / 1219 / 1200 / 1220 / 1250mm width For Pipes and Verandas


    Profile of Aluzinc Coated Steel :
    The Plating Coat Of Aluminum - zinc Alloy Armor Plate Is Zn - Al Alloy , And Its Composition Is 55 % Al , 43.4 % Zn And 1.6 % Si . The Plate is of Smooth Surface And Excellent Corrosion Resistance Of The Atmosphere , Which Is 2 To 6 Times Higher Than Hot-Dip Galvanized Sheet Of The Same Thickness Of Plating Coating.

    After Through Three Processes , Including Payoff Reel , Crop Shear And Welding , Enter Into The Continuous Annealing Furnace . During The Annealing Process , Strips Are Heated Closer To The Recrystallizing Temperature , And Then Heated To 20 - 50 Above The Recrystallizing Temperature In The Reducing Furnace . After Keep The Same Temperature For 170 s , Strips Are Naturally Cooled To The Normal Temperature In The Low Cooling Process . Afterward , Strips Enter Into The Zn - Al Pot Through The Elephant ‘ s Trunk And Begin In The Hot - Dip Coating Process . The Optimum Temperature Rang Of The Plating Coat Is 630 660 . Coated With Aluminium - Zinc Alloy , Strips Enter Into The Cooling Tower By The Steady Roll And Air Knife . After Fast Cooled With Wind Or Water , They Are Directly Produced Into Al - Zn Armor Plates .The General Rate Of Cooling Is 30 / s , And Strips Are Cooled To About 60 .


    Specifications :

    ■Standard : ASTM A792 / JIS G3321 / GB/T14978-2008 / EN10326-2004
    ■Grade : SGLCC / SGLCD / SGLC400~570 / DC51D+AZ~DC54D+AZ
    ■Thickness : 0.15-2.5 mm
    ■Width : 600 - 1250 mm ( Usually 914 mm / 1219 mm / 1220 mm / 1250 mm)
    ■Base Metal : Cold - Rolled Steel
    ■Al-Zinc Coating : 50 - 150 g / sqm
    ■Coil Internal Diameter : 508 mm / 610 mm
    ■Surface Treatment : Chromate Passivated , Non - Chromate Passivated , Oiled , Anti - finger Print And Etc
    ■tolerance thickness : + / - 0.05 mm , tolerance width : + 5 / - 2 mm , total quantity : + / - 10 % , alu - zinc coating : + / - 10 %
    ■Packing Condition : Seaworthy

    Characteristics of Aluzinc Coated Steel :
    GL are 3 ~ 6 times more corrosion - resistant compared to GI , but has a similar level of processability and weldability and can replace GI, and in particular is most suitable when replacing GI that require thick galvanized layers and high corrosion resistance .
    Only galvanized steel sheet that is used for roofing and walls without painting because of its unique silver spangles and beautiful appearance and high - corrosion resistance, and is used as a cool roofing material because of its excellent heat reflection qualities .
    Can replace aluminum gilded steel sheets because for certain purposes of its electrical conductivity and its heat-resistance qualities even at high temperatures that do not exceed 315 ℃ .
    Has greater surface hardness than GIs , and is much more wear - resistant .

    Product Application :
    Infrastructure : Roofing / External Siding / Garage / Shutter
    Household Appliances : Oven / Air - Conditioning Ventilation System / Solar Water Heater / Electronics
    Automobile : Mobile Muffler / Vent Pipe / Catalysis Converter Heater Shield / Bottom Accessories
    Industrial Instrument : Electric Control Cabinet / Industrial Freezer Chest

    Chemical Requirements :

    Chemical Requirements For Structure Steel


    Composition , % - Heat Analysis Element , Maximum , Unless Otherwise Shown
    DesignationCMnPSCuNiCrMoVCbTiaNb
    G2300.201.350.040.040.250.200.150.060.0080.0080.025*
    G2550.201.350.100.040.250.200.150.060.0080.0080.025*
    G2750.251.350.100.040.250.200.150.060.0080.0080.025*
    G3400.251.350.200.040.250.200.150.060.0080.0080.025*
    G5500.201.350.040.040.250.200.150.060.0080.0150.025*
